Plasma Technics currently sells over 30 Plasma Block OEM products that vary in ozone generating capacity from 5 to 600 grams/hour. Some units are air cooled, the higher volume units are water cooled. All products are micro processor based and many are UL/CSA listed. For more textual references see: Support Links.
-
Low frequency, severe application ozone transformers designed specifically for harsh electrical and environmental demands imposed by continuous duty, corona discharge ozone generation and electrostatic applications. All copper windings and a rugged high-temperature and high-voltage insulation system, housed in a very compact hermetically sealed enclosure, ensure operation at 85°C.
Case size 100, 200, 300, 400
UL & CSA Recognized Component.- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty, corona-discharge ozone- generation and electrostatic applications. UL & CSA Recognized Component.
- State-of-the-art, commercial-quality,design features assure a significant increase in operational performance, where standard ignition and neon transformers routinely fail.
- Cost-effective, compact and high generation-efficient design typically capable of supporting twice the ozone generation load of a conventional transformer.
- Hermetically sealed for long service life in severe service applications such as corona-discharge ozone-generation, electrostatics, and static bars. 2-year limited warranty
-
The standard 30g ozone generating block built with a water-cooling plate vs a fan and heat sink. Inverters and power supply are ordered seperate. Improved performance due to the water cooling. Precision-machined aluminum block eliminates inefficient hot spots. Optimum performance pressure band from 10 psi to 20 psi. Stackable: very cost-effective.
-
20khz design for high ozone production and long service life in severe service applications. Silent, state of the art, commercial quality, patented design features assure significant increase in operational performance. Both the 50 and 100 watt products are UL & CSA Recognized Components. Output current is adjustable via onboard potentiometer.
- 20khz design for high ozone production and long service life in severe service applications such as corona discharge ozone generation, electrostatics, and static bars.
- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty corona discharge ozone- generation and electrostatic applications. UL & CSA Recognized Components.
- Silent, state-of-the-art, commercial quality, patented design features assure significant increase in operational performance.
- Cost-effective, field-proven, compact, lightweight and high- generation-efficient design. 1 year limited warranty.
- Optional 4-20ma Opto-Coupled Interface to facilitate ORP, PLC and computer control.
-
Firmware running on all DAT series PCBs. Includes PlasmaBlocks, PTI Inverters and related Component products. Summary of all firmware release features (3.2 - 3.5) with links to related documentation and comments on known issues.
-
Solid State High Voltage Module 12 - 17vdc.
Designed specifically for under-the-counter continuous or intermittent duty corona-discharge ozone-generation and electrostatic applications. Ideal for point of use applications such as small pools, hot tubs, campers, recreational vehicles and yachts. State-of-the-art design operates at the nominal frequency of 1khz and automatically compensates for variations in line voltage.
- Designed specifically for under-the-counter continuous or intermittent duty corona-discharge ozone-generation and electrostatic applications. Ideal for point of use applications such as small pools, hot tubs, campers, recreational vehicles and yachts.
- State-of-the-art design operates at the nominal frequency of 1khz and automatically compensates for variations in line voltage.
- Cost effective, compact and low-voltage design, intended to simplify the UL approval process.
- 1 year limited warranty.
-
Rectifier with Link Choke and Soft Start Assembly. Reduces installation expense and complexity. Designed for simplifying installations of all the components necessary for generators with inverters integral to the PlasmaBlock®. Soft start feature to prevent startup current surges from weakening circuit breakers. 5 KW (16 Amp DC @ 208 – 240 VAC) rating.
Designed for simplifying installations of all the components necessary for:
- Generators with inverters integral to the PlasmaBlock®
- QuadBlock® generators requiring DC power
- Soft start feature to prevent startup current surges from weakening circuit breakers
- Power factor correction to 0.95 for accurate current measurements
- Three phase 208 – 240 VAC rectification for single phase high frequency output
- 5 KW (16 Amp DC @ 208 – 240 VAC) rating
- Single phase version to 2.5 KW (7 Amp) available
- Additional DC filtering extends component life
-
Rectifier with Link Choke and Power Conditioning Module.
Variations available 7 - 28 amps to give the best power factor match. Use on Plasma Block products up to and including 3500 watts. For use with 240v 3Ø, 28 amp max or 240v single phase, 15 amp max. Eliminates transient voltage spikes to DAT210 Inverters and Plasma Block Units often caused by contact interruption at full power.
-
Low to medium frequency, severe application ozone transformers designed specifically for harsh electrical and environmental demands imposed by continuous duty, corona discharge ozone generation and electrostatic applications. Increased Ozone production as a result of matching transformer designs with the capacitive ozone load. This yields greater ozone production with lower primary input current, reduced package size, and competitive over-all cost.
Case size 100, 110, 200, 210, 300, 400
UL & CSA Recognized Component.- Increased Ozone production as a result of matching transformer designs with the capacitive ozone load. This yields greater ozone production with lower primary input current, reduced package size, and competitive over-all cost.
- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty, corona-discharge, ozone generation, and electrostatic applications.
- State-of-the-art, commercial-quality, design features assure significant increase in operational performance, where standard air type transformers routinely fail.
- Cost-effective, compact and high generation-efficient design, typically capable of supporting twice the ozone-generation load of a conventional transformer.
-
Medium frequency, severe application ozone transformers designed specifically for harsh electrical and environmental demands imposed by continuous duty,corona discharge ozone generation and electrostatic applications. Hermetically sealed for long service life in severe service applications. Consistent performance, high loading capacity and long life. Separate ground stud ensures proper grounding to the generator and enclosure. Guaranteed secondary phasing eliminates high-voltage flash-over between transformers and secondary wiring in systems with multiple transformers.
- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty, high-frequency, corona- discharge, ozone-generation and electrostatic applications.
- State-of-the-art, commercial-quality, design features assure a significant increase in operational performance where standard automotive ignition coils routinely fail.
- Cost-effective, compact and high generation-efficient design typically capable of supporting twice the ozone generation load of a conventional transformer.
- Hermetically sealed for long service life in severe service applications, such as corona-discharge, ozone-generation, electrostatics and static bars. 2-year limited warranty.
-
Transformers designed specifically for harsh electrical and environmental demands. Vacuum impregnation sealed for long service life. These transformers are NOT oil filled. Complex impregnation and premium materials surround the critical components, ensuring a virtual corona-free operating environment within the enclosure, and a long service life that rivals oil. Cost-effective, compact, and high generation efficiency design.
- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty, corona-discharge, ozone-generation, and electrostatic applications. UL and CSA Recognized Component. CE rating on the 220v line of products.
- Completely sealed for Maximum Life, and Resistance to harsh environments, the design features assure a significant increase in operational performance where standard ignition and neon transformers routinely fail.
- Cost-effective, compact and high generation-efficient design, typically capable of supporting twice the ozone generation load of a conventional transformer.
- Vacuum impregnation-sealed for long service life in severe service applications such as corona-discharge, ozone-generation, electrostatics, and static bars. 2-year limited warranty for all applications including corona-discharge ozone generation.
Now conforms to European Union requirements.
-
Inverter components designed specifically for harsh electrical and environmental demands.
- Designed to provide maximum efficiency by allowing digital pulse drive by SSD and ATI series inverters. Magnets package converts pulse waveform to sine wave on cells for energy-efficient operation.
- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty, high-frequency, corona- discharge ozone, plasma generation, and electrostatic applications.
- Cost-effective, compact and high generation-efficient design typically capable of supporting twice the ozone generation load of conventional components.
- Dry type of encapsulation provides the highest reliability in harsh increments, second to liquid filled.
-
Inverter components designed specifically for harsh electrical and environmental demands.
- Designed to provide maximum efficiency by allowing digital pulse drive by SSD and ATI series inverters. Magnets package converts pulse waveform to sine wave on cells for energy-efficient operation.
- Designed specifically for harsh electrical and environmental demands imposed by continuous-duty, high-frequency, corona- discharge ozone, plasma generation, and electrostatic applications.
- Cost-effective, compact and high generation-efficient design typically capable of supporting twice the ozone generation load of conventional components.
- Dry type of encapsulation provides the highest reliability in harsh increments, second to liquid filled.
-
Across the board product upgrade, all future PlasmaBlock® orders will migrate to Gen1 Enhanced internals. The internal changes in the Gen1 ozone blocks result in improved oxygen flow and less contamination sensitivity. Customers should experience a longer service life with this line of products. Optimum performance is at 10psi or less.
-
The Temperature Sensor Board is a small circuit used to select and output the highest temperature reading among a set of temperature sensors. Intended for thermally similar situations. Included with all multiblock systems. Tandem provision. Up to four (4) temperature sensors per temperature board. Output terminal connects to a DAT210/310 inverter's temperature sensor.
-
A small device with software that provides a new way to connect and communicate with your PlasmaBlock®. The PlasmaLINK unit connects to the DAT series board on PlasmaBlock® units. Collect, store and analyze performance data from local or remote locations. Monitor performance and/or troubleshoot a unit from local or remote locations.
Links Available:
WiFi
USB
RS232 via USB and Keyspan
Ethernet
HDMI -
The DAT210 inverter assembly simplifies assembly and solves several circuit problems that shorten component life. Soft start feature prevents startup current surges from weakening circuit breakers. DAT210 (Digital Auto Tuning) compensates for generator pressure and flow changes automatically. Tested assembly reduces installation mistakes. Reduces inverter mains current by about 50%.
-
A necessary item when fuses are sized close to the running current at the installation site. Code 70258. Due to the wide variety of fuse types it is not feasible to offer a more specific recommendation. Soft start feature to prevent startup current surges from weakening circuit breakers.
NOT recommended for use with DAT310
-
A line of higher concentration ozone generators by plasma technics inc. After extensive R & D a line of more efficient and higher concentration ozone generators.
Introducing the Gen2 PlasmaBlocks. A new line of PlasmaBlock® products with a significant improvement in watt hours/lb of ozone (e.g. more ozone for the same power consumption). This results in either a higher volume or concentration. Ozone concentration on air-cooled units will be 10-12wt%, even higher for water-cooled units with power consumption remaining about the same.
Only the internals of the block are changed in the Gen2 line. The product footprint, size, appearance, dimensions, power consumption and control remain identical to the current PlasmaBlock® line. Gen2 products can be substituted into existing equipment.
Watch for additional performance details on each product in the near future.
All current PlasmaBlock® products will have a Gen2 equivalent. All Gen1 products are and will remain available for customers who do not require or want the performance of Gen2.
Price increase, a modest 20 - 40% by product.
-
The smallest PlasmaBlock® unit. Available with a regular (PCB on the side) or alternate (PCB on top) mount. Regular mount has connection ports (oxygen in, ozone out) on top, alternate mount has ports on the side. The 3/7g chassis is a miniature version of the 10g unit.
For added application information, see the PlasmaBlock Application Guide
Models available
Refer to - Configuration Options Summary SheetFully automatic tuning for constant ozone output and installation simplicity
Service simplicity due to automatic fault diagnostics
Silent, Rugged, Reliable and Cost Effective
No exposed high-voltage safety hazards
3g @ 0.5% Air and 7g @ 5% Oxygen models in same chassis
Now available with PlasmaVIEW ® software (optional) -
The DAT210 Inverter Assembly solves several circuit problems that shorten component life and simplifies assembly of products at an install site. For use with 240v 3Ø, 25 amp max or 240v single phase. To optimize power factor correction for other currents, see this table.
-
Software that allows the technician or engineer to connect a personal computer to any PlasmaBlock® processor for diagnostics and/or datalog purposes.
PlasmaVIEW® software provides charts for all measurement parameters with the time base limited only by the disk space available. PlasmaVIEW® writes data to your pc disk-drive, enabling delayed viewing, retrieval, analysis and email. Configuration files can be extracted to use in setups for additional installations of the same application on other units.
-
NOT FOR NEW DESIGN
Available in two mounting options.
The 10/20g chassis is a miniature version of the 50g unit. Available with a regular (PCB on the side) or alternate (PCB on top) mount. Regular mount has connection ports (oxygen in, ozone out) on top, alternate mount has ports on the side.
For added application information, see the PlasmaBlock Application Guide
Models available
Refer to - Configuration Options Summary SheetFully automatic tuning for constant ozone output and installation simplicity
Service simplicity due to automatic fault diagnostics
Silent, Rugged, Reliable and Cost Effective
No exposed high-voltage safety hazards
10g and 20g models in same chassis
Now available with PlasmaVIEW ® software (optional) -
The DAT210 is a new Microcontroller design that automatically determines the optimum system operating frequency (resonance). Years in the making, this technology will, for the first time, make high-efficiency self optimizing systems available to everyone. This single-phase inverter provides a linear means to adjust corona by using Pulse Density Modulation (PDM), with frequencies up to 30khz. This control scheme allows the inverter to use the full potential of the IGBTs by reducing the usual high-frequency switching losses. Automatic buss-voltage compensation stabilizes the output as power line conditions change. PTI has specifically designed transformers to mate with the DAT210, thereby providing a complete high- voltage solution. Microcontroller design provides unprecedented control integration.
Applications
- Ozone system variable-frequency voltage drive and Pulse Density Modulation.
- Non-thermal plasma or cold plasma systems.
- Applications requiring good plasma coverage at extreme turn down, such as 1%.
- Corona Treatment and Static Eliminator systems.
- High-frequency, high-current supplies for laboratory use.
- DC to Single-phase output conversion for crane and gantry lighting.
- Now available with PlasmaVIEW ® software.
- Programming and Troubleshooting.
- Web Interactive Troubleshooting.
-
The smallest PlasmaBlock® unit with water cooling for greater ozone output.
A water cooled version of the smallest PlasmaBlock®. Major savings due to its low energy use, low oxygen volume needs and competitive price. This Gen2 cell is a scaled down version of PTI’s field proven 50g product which is virtually impervious to extremes in temperature, vibration and pressure.
For added application information, see the Plasma Block® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Fully automatic tuning for constant ozone output and installation simplicity
- Service simplicity due to automatic fault diagnostics
- Silent, Rugged, Reliable and Cost Effective
- No exposed high-voltage safety hazards
- Now available with PlasmaVIEW ® software (optional)
-
Plasma Block® component parts enabling companies to build their own or replace parts of their existing ozone generating equipment as needed. These component parts are the same ones used in existing PTI products.
-
The DAT410 Inverter Assembly incorporates PTI's most advanced powerline interfacing logic. It builds off of the DAT210 platform but monitors more powerline variables and reacts with feedback loop utilizing relays and dry contacts for seamless integration into an industrial control cabinet.
-
Plasma Block component parts enabling companies to build their own or replace parts of their existing ozone generating equipment as needed. Ozone cells are available in a single, double or triple stack, all with a common mounting bracket. Available in Gen1 or Gen2. These component parts are the same ones used in existing PTI products.
-
A Micro-controller design that automatically determines the optimum system operating frequency (resonance). This product makes high-efficiency self optimizing systems available to everyone. The SSD110 is a new, second-generation, Pulse Density Modulation (PDM) enhanced, single-phase inverter providing linear plasma control with a turn-down to 10%. Higher power capacity, enhanced controls, improved internal fault protection and identical mounting are the product’s cornerstones. With twice the usable power level of its predecessor, an extended frequency range and onboard controls to simplify installation, the new SSD110 is a great value. An automatic buss voltage compensation circuit stabilizes the high voltage output. PTI also has specifically designed transformers to mate with the SSD product series to provide a complete high voltage solution.
Applications
- Ozone system variable frequency & voltage drive, NOx Conversion and Eximer Lamp supplies.
- Corona Treatment and Static Eliminator systems.
- Military applications requiring 400 hz (cycles per second).
- Spindle-drive supplies requiring frequencies higher than normal PWM inverters can supply.
- Variable-Speed Single-phase AC motor supplies, DC to Single-phase output conversion.
-
A long term staple in the PlasmaBlock® product line. Block subassemblies available in a water cooled version. Contains all the durability and features of the newer models. Now available with a Gen 1 Enhanced and Gen 2 blocks for higher volume or ozone production. 23 kHz operating frequency, for silent operation; Line voltage 120v or 240v, 50/60hz.
For added application information, see the Plasma Block® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Cost-effective, Compact and Light Weight, Ceramic, Air-cooled and power-Efficient.
- 1.1 lbs/day at 6.7% and 3 LPM : 1.9 lbs/day at 3.5% weight and 10 LPM (Oxygen or Concentrator)
- No exposed, high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Control with Turn-down to 1%.
- Now Available with PlasmaVIEW ® software (optional)
-
PTI now offers Plasma Block component parts enabling companies to build their own or replace parts of their existing ozone generating equipment as needed.
Prior to this, all PTI ozone generating products included a complete package consisting of an Inverter, Transformer, Ozone cell and cooling (water and/or air). Now companies can build their own or replace parts as needed.
These component parts are the same ones used in existing PTI products.
PDM, Voltage and Frequency potentiometers have their own jumper selection for onboard control if desired.
-
The 1105 digital AC inverter provides flexible, efficient and cost-effective solutions to a range of control needs. It combines the latest IGBT-based PWM and digital-signal processor technologies with a revolutionary, patented digital-current regulator to deliver optimum performance, full programmability, and simplicity of operation. Compact and rugged, the inverter comes as an open chassis or in a NEMA 4 enclosure. Either type can be foot-mounted to a sub-plate or flange-mounted through a cutout, to dissipate heat outside an enclosure.
-
A new block design in the PlasmaBlock® line. Features a one-piece block and heat sink for more efficient heat dissipation and greater ozone generation related to it's overall size.
24g / hr (1.3 ppd)@ 8% weight and 3 lpm. 40g / hr (2.1 ppd) @ 5% weight and 10 lpm (oxygen or concentrator) at 300 watts.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Cost-effective, Compact and Light Weight, Ceramic, Air-cooled and power-Efficient.
- 24g / hr (1.3 ppd)@ 8% weight and 3 lpm. 40g / hr (2.1 ppd) @ 5% weight and 10 lpm (oxygen or
- concentrator at 300 watts.
- No exposed, high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Control with Turn-down to 1%.
- Useful pressure range: 5 – 100 psi.
- Now available with PlasmaVIEW ® software (optional).
-
A staple in the PlasmaBlock® mid size product line. Same internal ozone generating block as the 30g, mounted vertically with additional cooling for greater capacity. Also available in a dual-cool version, a Gen 1 Enhanced, and a Gen 2 block. 23 kHz operating frequency for silent operation. Line voltage 120v or 240v, 50/60hz.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Cost-effective, Compact and Light Weight, Ceramic, Air-cooled and power-Efficient.
- 1.3 lbs/day at 7.7% and 3 LPM : 3.6 lbs/day at 4.2% weight and 15 LPM (Oxygen or Concentrator).
- No exposed high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Control with Turn-down to 1%.
- Useful pressure range: 5 – 100 psi.
- Now available with PlasmaVIEW® software (optional).
-
Same mid size block as the 60g air cooled with a water cooling plate added for additional heat dissipation and related ozone output. Same chassis as the 60g air cooled unit. No outside cooling air is needed since the water and fan removes heat from the enclosure and it's block. One or two fan models.
The added cooling of water plus enclosure heat removal provides a unique feature over the standard 30g
air-cooled unit. More ozone output (60g vs 30g on a standard 30g chassis). No outside cooling air is
needed since the water and fan removes heat from the enclosure and it's block. In a normal rugged
environment it can be placed in a sealed enclosure with no outside air or filters needed, which
also means less maintenance. Cooling is not sufficient to accomodate a concentrator in the sealed
enclosure.For added application information, see the PlasmaBlock® Application Guide manual.
Models Available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Cost-effective, Compact and Light Weight, Ceramic, Air-cooled and power-Efficient.
- 1.3 lbs/day at 7.7% and 3 LPM : 3.6 lbs/day at 4.2% weight and 15 LPM (Oxygen or Concentrator).
- No exposed high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Control with Turn-down to 1%.
- Useful pressure range: 5 – 100 psi. (sweet spot - 20psi)
- Now available with PlasmaVIEW® software (optional).
-
A new design PlasmaBlock® featuring a one-piece block/heat sink that dissipates heat more efficiently and allows greater ozone generation related to it's overall size. The Gen2 block in this product will produce 65g per hour of 10% wt ozone. Service simplicity due to automatic fault diagnostics.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Stand Alone
Fully automatic tuning for constant ozone output and installation simplicity
Service simplicity due to automatic fault diagnostics
Silent, Rugged, Reliable and Cost Effective
No exposed high-voltage safety hazards
Now available with PlasmaVIEW ® software (optional) -
A staple in the PlasmaBlock® line yet contains all the durability and features of the newer models. Available in two different mounting heights and with a Gen1 or Gen2 ozone block. The ozone generating blocks are available as a component. Air-cooled and power-Efficient. 1.5 lbs/day at 9.2% and 3 LPM : 8 lbs/day at 4.7% weight and 30 LPM (Oxygen or Concentrator).
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Cost-effective, Compact and Light Weight, Ceramic, Air-cooled and power-Efficient.
1.5 lbs/day at 9.2% and 3 LPM : 8 lbs/day at 4.7% weight and 30 LPM (Oxygen or Concentrator). - No exposed high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Linear Control with Turn-down to 1%.
- Useful pressure range: 5 – 100 psi.
- Now available with PlasmaVIEW ® software.
- Silent, Rugged, Reliable, Cost-effective, Compact and Light Weight, Ceramic, Air-cooled and power-Efficient.
-
A new design PlasmaBlock® featuring a one-piece block/heat sink that dissipates heat more efficiently and allows greater ozone generation related to it's overall size. The Gen1 enhanced block generates 170g per hour of 5% Wt. The Gen2 block generates 140g per hour of 10% Wt.
- Silent, Rugged, Reliable, Cost-effective
- Fully automatic tuning for constant ozone output and installation simplicity
- Service simplicity due to automatic fault diagnostics
- No exposed high-voltage safety hazards
- Now available with PlasmaVIEW® software (optional).
For additional application information, see the PlasmaBlock® Application Guide Manual.
-
A medium size water-cooled PlasmaBlock® product with a small footprint and height when compared to other models. 1.7 lbs/day at 9.5% 3 LPM; 8 lbs/day at 4.7% weight 30 LPM (Oxygen or Concentrator). Useful pressure range: 5 – 98 psi. 23 kHz operating frequency for silent operation. Precise Linear Control with Turndown to 1%.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Safe, Efficient, Cost-effective, Compact, Light-Weight, Ceramic dielectrics.
- 1.7 lbs/day at 9.5% and 3 LPM; 8 lbs/day at 4.7% weight and 30 LPM (Oxygen or Concentrator).
- No exposed high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Linear Control with Turndown to 1%.
- Useful pressure range: 5 – 98 psi.
- Now available with PlasmaVIEW® software (optional).
-
A variable sized water-cooled PlasmaBlock® product available with one, two, or three water cooled blocks with Ozone output of 200g, 400g, or 600g at 5% wt, or 150g, 300g, or 450g at 10% wt. Blocks available in GenE or Gen2. For other concentrations, see performance graphs.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, and Cost-effective.
- No exposed high-voltage safety hazards.
- Fully automatic tuning for constant ozone output and installation simplicity.
- Service simplicity due to automatic fault diagnostics.
- Now available with PlasmaVIEW® software (optional).
-
A staple in the PlasmaBlock® line. A large size PlasmaBlock® unit containing multiple ozone blocks. Available with Gen1 or Gen2 internals. 3.4 lbs/day at 9.5% wt 6 LPM; 16 lbs/day at 4.7% wt 60 LPM (Oxygen or Concentrator). Pre-mounted, seasoned and tested package sub-system which includes individual operational status indicators for each Plasma Block® , PDM controlled inverter, fans.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Safe, Efficient, Cost-effective, Compact, Light-Weight, Ceramic dielectrics.
- 3.4 lbs/day at 9.5% and 6 LPM; 16 lbs/day at 4.7% weight and 60 LPM (Oxygen or Concentrator).
- No exposed high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Linear Control with Turndown to 1%
- Useful pressure range: 5-98 psi.
- Now available with PlasmaVIEW® software (optional).
-
The largest size PlasmaBlock® unit containing multiple ozone subassembly blocks. Available with Gen1 or Gen2 internals. 5.2 lbs/day at 9.5% and 9 LPM; 24 lbs/day at 4.7% weight and 90 LPM (Oxygen or Concentrator). Pre-mounted, seasoned and tested package sub-system which includes individual operational status indicators for each Plasma Block® , PDM controlled inverter, fans.
For added application information, see the PlasmaBlock® Application Guide manual.
Models available
Refer to - Configuration Options Summary Sheet
- Silent, Rugged, Reliable, Safe, Efficient, Cost-effective, Compact, Light-Weight, Ceramic dielectrics.
- 5.2 lbs/day at 9.5% and 9 LPM; 24 lbs/day at 4.7% weight and 90 LPM (Oxygen or Concentrator).
- No exposed high-voltage safety hazards.
- Precise ozone control using Pulse Density Modulation (PDM) via potentiometer, 4/20ma or 0-10vdc.
- Precise Linear Control with Turn-down to 1%.
- Useful pressure range: 5 – 100 psi.
- Now available with PlasmaVIEW® software (optional).
-
One of the most efficient PlasmaBlock® products. A larger PlasmaBlock® intended for use at installations where multiple units are interconnected to produce large amounts of ozone. Marketed exclusively by Pinnacle Ozone.
